RX3041 Router User's Manual
5
1.3.2 Rear Panel
The rear panel contains the ports for the unit’s data and
power connections.
Label Indication
POWER Power Input Jack: connects to the supplied AC adapter.
WAN WAN Port: connects to your WAN device, such as ADSL or cable
modem.
LAN (1-4) LAN Ports: connects to your PC’s Ethernet port, or to the uplink
port on your LAN’s hub/switch, using the Ethernet cable.
RESET Reset Button:
1. Reset the system configuration to the factory defaults, if
pressed for more than 4 seconds.
2. Reboot the device if pressed for more than 20 seconds.
