ix
M5A78L-M Series specifications summary
(continued on the next page)
CPU AMD ® Socket AM3+ for AMD ® FX™ / Phenom™ II / Athlon™ II /
Sempron™ 100 series processors
Supports 32nm AM3+ CPU
AMD ® Cool ‘n’ Quiet™ Technology
Supports CPU up to 95W
* Refer to www.asus.com for the AMD ® CPU support list
Chipset AMD ® 760G (780L) / SB710
System bus Up to 5200 MT/s HyperTransport™ 3.0 interface
Memory 2 x DIMM, max. 16GB, DDR3 1866(O.C.) / 1600(O.C.) / 1333 /
1066 MHz, ECC and non-ECC, un-buffered memory
Dual-channel memory architecture
* AMD ® FX™ Series CPU on this motherboard supports up to
DDR3 1866MHz as its standard memory frequency.
** Due to CPU spec., AMD ® 100 and 200 series CPUs support
up to DDR3 1066MHz. With ASUS design, this motherboard
can support up to DDR3 1333MHz.
*** When overclocking, some AMD CPU models may not support
DDR3 1600 MHz or higher frequency DIMMs.
**** Refer to www.asus.com for the latest Memory QVL
(Qualified Vendors List).
***** When you install a total memory of 4GB or more, Windows ®
32-bit operating system may only recognize less than 3GB.
We recommend a maximum of 3GB system memory if you
are using a Windows ® 32-bit operating system.
Graphics Integrated ATI Radeon™ HD 3000 GPU
Supports max. shared memory of 1GB
Supports DVI-D compliant with HDCP with max. resolution of
2560 x 1600 (@60Hz)
Supports RGB with max. resolution of 2048 x 1536 (@75Hz)
Supports Hybrid CrossFireX™
* Refer to www.amd.com for the discrete GPUs that support
Hybrid CrossFireX™.
Expansion slots 1 x PCIe 2.0 x16 slot
1 x PCIe 2.0 x1 slot
2 x PCI slots
Storage
6 x Serial ATA 3Gb/s connectors support RAID 0, RAID 1,
RAID 10, and JBOD configurations
LAN
Realtek ® 8111E PCle Gigabit LAN controller
Audio ALC887 8-channel* High Definition Audio CODEC
* Use a chassis with HD audio module in the front panel to
support an 8-channel audio output.
USB AMD ® SB710 chipset:
- 12 x USB 2.0/1.1 ports (8 ports at the mid-board, 4 ports at
the back panel)
