ASUS E35M1-M Series 1-18
5. Digital audio connector (4-1 pin SPDIF_OUT)
This connector is for an additional Sony/Philips Digital Interface (S/PDIF) port. Connect
the S/PDIF Out module cable to this connector, then install the module to a slot
opening at the back of the system chassis.
The S/PDIF module is purchased separately.
SPDIF_OUT
+5
V
SPDIFOU
T
GND
E35M1-M PRO
E35M1-M PRO Digital audio connector
4. Serial ATA 6.0Gb/s connectors (7-pin SATA6G_1~5)
These connectors connect to Serial ATA 6.0 Gb/s hard disk drives via Serial ATA 6.0
Gb/s signal cables.
• These connectors are set to [IDE Mode] by default. In IDE mode, you can connect
Serial ATA boot/data hard disk drives to these connectors. See section 2.5.2 SATA
Configuration for details.
• When using hot-plug and NCQ, set the OnChip SATA Type item in the BIOS to [AHCI
Mode]. See section 2.5.2 SATA Configuration for details.
GN
D
RSATA_TXP
1
RSATA_TXN1
GN
D
RSATA_RXP
1
RSATA_RXN1
GN
D
SATA6G_1 SATA6G_2
GN
D
RSATA_TXP
2
RSATA_TXN2
GN
D
RSATA_RXP
2
RSATA_RXN2
GN
D
GN
D
RSATA_TXP
3
RSATA_TXN3
GN
D
RSATA_RXP
3
RSATA_RXN3
GN
D
SATA6G_3
GND
RSATA_RXN5
RSATA_RXP5
GND
RSATA_TXN5
RSATA_TXP5
GND
SATA6G_5 SATA6G_4
GN
D
RSATA_TXP
4
RSATA_TXN4
GN
D
RSATA_RXP
4
RSATA_RXN4
GN
D
E35M1-M PRO
E35M1-M PRO SATA connectors
