xii
Rampage III GENE specifications summary
CPU LGA1366 socket for Intel ® Core™i7 Processor Extreme
Edition / Core™i7 Processors
- Support Intel
® Turbo Boost Technology
* Refer to www.asus.com for Intel CPU support list
Chipset Intel ® X58/ICH10R
System Bus Up to 6.4 GT/s with QuickPath Interconnection
Memory Triple channel memory architecture
6 x DIMM, max. 24GB, DDR3 2200(O.C.)/2133(O.
C.)/2000(O.C)/1800(O.C.)/1600/1333/1066 MHz, non-
C.)/2000(O.C)/1800(O.C.)/1600/1333/1066 MHz, non-
ECC, un-buffered memory modules ECC, un-buffered memory modules
Supports Intel ® Extreme Memory Profile (XMP)
*Hyper DIMM support is subject to the physical
characteristics of individual CPUs.
characteristics of individual CPUs.
*Refer to www.asus.com or this user manual for the
Memory QVL (Qualified Vendors Lidts)..
Memory QVL (Qualified Vendors Lidts)..
Expansion Slots 2 x PCIe2.0 x16 slots, support dual x16 mode
1 x PCIe x4
1 x PCI 2.2
Multi-GPU Technology Support NVIDIA SLI™ / ATI CrossFireX™ Technology
Storage ICH10R Southbridge:
- 6 x SATA 3.0 Gb/s ports (gray) 6 x SATA 3.0 Gb/s ports (gray)
- Intel Matrix Storage Technology supports RAID 0, 1, Intel Matrix Storage Technology supports RAID 0, 1,
5 and 10 5 and 10
Marvell ® PCIe 9128 SATA 6Gb/s controller
- 2 x SATA 6.0 Gb/s ports (red) 2 x SATA 6.0 Gb/s ports (red)
LAN Intel ® Gigabit LAN
High Definition Audio SupremeFX X-Fi 2 built-in
- 8-channel High Definition Audio CODEC 8-channel High Definition Audio CODEC
- EAX EAX ® Advanced™ HD 5.0
- THX TrueStudio PC THX TrueStudio PC
- X-Fi X-Fi ® Xtreme Fidelity™
- Creative ALchemy Creative ALchemy
- Supports Blu-ray audio layer content protection Supports Blu-ray audio layer content protection
- Supports Jack-detection, Multi-streaming, Front Supports Jack-detection, Multi-streaming, Front
Panel Jack-retasking Panel Jack-retasking
- Supports 1 x Optical S/PDIF out port at back panel Supports 1 x Optical S/PDIF out port at back panel
IEEE 1394 2 x 1394a ports (1 port at back panel, 1 port at midboard)
USB NEC ® USB 3.0 controller
- 2 x USB 3.0/2.0 ports (at back panel)
Intel ® ICH10R Southbridge
- 11 x USB 2.0/1.1 ports (4 ports at midboard; 6 ports
at back panel, 1 reserved for ROG Connect)
(continued on the next page)
