8. Front panel audio connectors (10-1 pin FPAUDIO)
This is an interface for front panel audio cable that allows convenient
connection and control of audio devices.
9. OnBoard LED
The green Light Emitting Diode (LED) lights-ON if there is standby power and
lights-OFF when the power is turned off.
A7N8X-VM 400
A7N8X-VM 400 Front Panel Audio Connector
FP_AUDIO
BLINE_OUT_L
MIC2
Line out_R
Line out_L
BLINE_OUT_R
NC
MICPWR
+5V
A
AGND
A7N8X-VM 400
A7N8X-VM 400 Onboard LED
SB_PWR1
ON
Standby
Power
OFF
Powered
Off
