ASUS A7N8X-VM 400 Motherboard

1-5

System Buzzer. The system buzzer allows you to hear system warning
beeps when a PC speaker is not available.

Audio CODEC. The Realtek ALC650 6-channel Audio CODEC is an
AC’97 compliant audio CODEC designed for PC multimedia systems.

PCI slots. These 32-bit PCI 2.2 expansion slots support bus master PCI
cards like SCSI or LAN cards with 133MB/s maximum output.

LAN chip. The Realtek 8201BL PHY Fast Ethernet controller allows
connection to a Local Area Network (LAN) through a network hub.

TV-out connector. This 6-1 pin connector is for a TV-out module
connector for an additional TV-out port.

PS/2 mouse port. This green 6-pin connector is for a PS/2 mouse.

Parallel port. This 25-pin port connects a parallel printer, a scanner, or
other devices.

RJ-45 port. Using the NVMAC

in the Southbridge controller and Realtek

8201BL PHY Fast Ethernet controller, this port allows connection to a Local
Area Network (LAN) through a network hub.

Line In jack. This Line In (light blue) jack connects a tape player or other
audio sources.

Line Out jack. This Line Out (lime) jack connects a headphone or a
speaker.

Microphone jack. This Mic (pink) jack connects a microphone.

USB 2.0/1.1 ports. These two 4-pin Universal Serial Bus 2.0/1.1 ports are
available for connecting USB devices such as a mouse and PDA.

VGA port. This 15-pin VGA port connects to a VGA monitor.

Serial port. This port connects to your serial mouse and other serial
devices.

PS/2 keyboard port. This purple 6-pin connector is for a PS/2 keyboard.
