ix
P8H61-M LX3 specifications summary
(continued on the next page)
CPU LGA1155 socket for Intel ® Second Generation processors
Supports Intel 32nm Multi-Core CPU
Supports Enhanced Intel ® SpeedStep Technology (EIST)
* Refer to www.asus.com for Intel ® CPU support list.
Chipset Intel ® H61 Express Chipset
Memory 2 x DIMM, max. 16GB, DDR3 1333 / 1066 MHz, non-ECC,
un-buffered memory
Dual-channel memory architecture
* The maximum 16GB memory capacity can be supported with
8GB or above DIMMs. ASUS will update the memory QVL once
the DIMMs are available in the market.
** Refer to www.asus.com for the latest Memory QVL (Qualified
Vendors List).
*** When you install a total memory of 4GB capacity or more,
Windows ® 32-bit operating system may only recognize less
than 3GB. We recommend a maximum of 3GB system memory
if you are using a Windows ® 32-bit operating system.
Expansion slots 1 x PCI Express 2.0 x16 slot with latch
1 x PCI Express 2.0 x1 slot
Graphics Supports D-Sub with max. resolution up to 2048 x 1536 @75Hz
Max. UMA Memory: 1748MB
Storage Intel ® H61 Express Chipset:
- 4 x Serial ATA 3.0 Gb/s connectors
LAN
Realtek ® 8111E PCIe Gigabit LAN controller
Audio VIA ® VT1708S 8-channel* High Definition Audio CODEC
- Supports Multi-Streaming
* Use a chassis with HD audio module in the front panel to
support an 8-channel audio output.
USB 10 x USB 2.0 ports (6 ports at the mid-board, 4 ports at the back
panel)
ASUS unique
features
ASUS Anti-Surge Protection
ASUS UEFI BIOS
ASUS Q-Fan 2
ASUS CrashFree BIOS 3
ASUS EZ Flash 2
ASUS MyLogo 2™
Rear panel ports 1 x PS/2 keyboard port (purple)
1 x PS/2 mouse port (green)
1 x D-Sub port
1 x LAN (RJ-45) port
4 x USB 2.0 ports
3 x Audio jacks
