Features and Benefits

Optical - SX Fiber Tap
Fiber Type: Corning Multimode 50 or 62.5/125μm,

850nm
Transceiver: GigaBit SX 850nm, VCSEL, supports 50 or

62.5/125μm
Monitor Port Output Power: -9.5 dBm

Network Connectors: LC

Monitor Connectors: SFP

Split Ratio: 50/50, 60/40

Optical - LX Fiber Tap
Fiber Type: Corning Singlemode 8.5/125μm, 1310nm

Transceiver: GigaBit LX 1310nm, supports 8.5/125μm

Monitor Port Output Power: -10 dBm

Network Connectors: LC

Monitor Connectors: SFP

Split Ratio: 50/50, 60/40

Electrical

Power Supply Input:
100-240VAC, 0.5A, 47-63Hz
Output:12V, 1.5A

Memory
1GB buffer

Environmental
Operating Temperature: 0˚C to 40˚C

Storage Temperature: -10˚C to 70˚C

Relative Humidity: 10% min, 95% max,

non-condensing

Mechanical
Dimensions: 1.125” high x 11” deep x 8.5” wide

Indicators
(1) 2x16 LCD

(3) Link LEDs

(2) Threshold Alarm LEDs

(2) Power LEDS

Software
Command Line Interface (CLI): Any terminal

emulation software
Net Optics Web Manager: Any browser

Net Optics System Manager: Windows 98,

Windows 2000, Windows XP

Available Base Models
GigaBit Multimode Fiber, SX, 62.5 μm
GigaBit Multimode Fiber, SX, 50 μm
GigaBit Singlemode Fiber, LX, 8.5 μm

Part Numbers
IPA-50SXx-SFP
IPA-SXx-SFP
IPA-LXx-SFP

Certifications
Fully RoHS compliant

Front Panel Display and LEDs

Real-time usage and peak traffic information displayed on the front panel saves you time and money spent using other tools to get basic information. Alarm
LEDs indicate if traffic levels have exceeded a set threshold, allowing you to respond quickly to changing traffic conditions.

Net Optics Web Manager

Without any specialized software, you can access the traffic information monitored by any iTap Port Aggregator. All you need is a computer with a browser and
access to the IP address of the iTap Port Aggregator. No matter where you are, you can control your iTap Port Aggregator and monitor traffic information.

Net Optics System Manager

Net Optics’ SNMP management tool, System Manager, gives you single-point control and visibility into any link in the network with an iTap Port Aggregator
anywhere in the world. Distributed on strategic links, iTap Port Aggregators provide baseline information and early warning alarms to help you deploy your
security and monitoring devices more effectively over more links.

Command Line Interface

The password-protected command line interface gives you complete access to all of iTap Port Aggregator’s functionality via an RS232 port. Most importantly,
you can use the CLI to disable the Management Port and prevent the front panel display from showing traffic information.

Net Optics Management
Information Base (MIB)

Use the iTap Port Aggregator with your current SNMP management tool. Net Optics’ MIB and SNMP traps are completely compatible with popular SNMP tools
such as OpenView and Tivoli

Aggregation

Net Optics’ proven port aggregation technology allows you to monitor traffic using a single NIC on your monitoring device. Unlike any other port aggregator
tap, the iTap Port Aggregator monitors usage levels of both sides of the full-duplex link so this information is not lost. 256MB traffic buffers help ensure that
your monitoring device does not miss traffic during bursts.

Cables Included

All cables required for installation are included. Follow the connection diagram on top of the iTap Port Aggregator and you are halfway done with the instal-
lation of your iTap Port Aggregator.
