1.4.2 Back View

All Data I/O connectors are protected by the back compartment cover.
Before making any connections, remove the back compartment cover.
Press the tab then pull back to detach the back compartment cover.

Figure 3: Back View

NOTE

The connectors may vary depending on the device model.
Some connectors shown above may not be on your device.
