CONTROL ELEMENTS
1. Power
button
2.
Channel down button (CH-)
3. USB
Port
4.
Channel up button (CH+)
5. IR
Receiver
Note:
The unit is automatically ready to work as soon as the power supply is applied.
Description of the elements:
1. Aerial
Input
2.
Loop Out Aerial output
3.
SCART output TV
4.
Digital audio output (coaxial
5.
► Audio out for Stereo
6.
CVBS Video out
7.
◄ Audio out for Stereo
Front Panel
Rear Panel
1. 2.
3.
5.
4.
7.
6.
5.
4.
3.
2.
1.
