SOLO 444 Motorsprühgerät User Manual
Page 23
Technical Specifications
ENGLISH
7
4. Technical Specifications
Mistblower
444
451
Engine type
SOLO single cylinder two-stroke engine
Engine capacity
cm
3
40.2
66.5
Bore / stroke
mm
40 / 32
46 / 40
Max Engine power (ISO 8893)
kW at rpm
1.5 / 6500
2.1 / 5750
Fuel tank capacity
l
1.5
1.9
Fuel mix ratio: with SOLO 2T Oil
with other two-stroke oils
1:50 (2%)
1:25 (4%)
Carburettor
All-position diaphragm carburettor with primer
and integrated fuel pump
Air filter cartridge
Paperstyle
Ignition
Electronically controlled magneto ignition,
maintenance free
Total Formula Tank Capacity
l
13
13 / 21 (Typ 451-02)
Nominal Formula Tank Capacity
l
12
12 / 20 (Typ 451-02)
Strain funneled mesh size
mm
0.55
Residual volume which the equipment cannoot
properly apply
ml
< 100
Strainer for accessory sets mesh size
mm
0.32
Max. Blower Air Volume *)
m
3
/h
900 1400
Weight
kg
10.0
10.8
Dimensions without Spray Tube
mm
hight: 690
width: 500
depth: 260
hight: 690
width: 550
depth: 280
Permissible speed
rpm
7000 ± 200
5600 ± 200
Maximum speed of the fan *)
rpm
5200
4300
Medium idling speed
rpm
2900 ± 200
2200 ± 200
In determining the following values regarding the acceleration of vibrations and sound, the different
operating conditions were weighted in accordance with the current standards
Sound pressure level L
Peq
dB(A)
(EN ISO 3744)
89 ± 2,5 dB(A)
94 ± 2,5 dB(A)
Sound power level L
Weq
dB(A)
(EN ISO 3744)
97 ± 2,5 dB(A)
103 ± 2,5 dB(A)
Weighted effective acceleration a
hv,eq
m/s
2
(EN ISO 5349)
< 2 ± 1m/s
2
< 2 ± 1m/s
2
*)
without Spray Tube
