PC2000-PC/104 Data Sheet
Specifications
Specifications Criteria
Absolute Maximum Ratings:
V
CC
Voltage on any pin
+ 5.5 VDC
Vcc + 0.2 VDC
Physical Specifications:
Physical Dimensions (no enclosure)
Weight
4.05 (W) x 3.78 (L) x 0.70 (H) inches
200 g
Power:
Power requirement (master)
Supply voltage
Power-up time
250 mA at +5 VDC
4.5 – 5.5 V
3 msec
Spectrometer:
Design
Focal length (input)
Focal length (output)
Input Fiber Connector
Gratings
Entrance Slit
Detector
Filters
Asymmetric crossed Czerny-Turner
42mm
68mm (75, 83 and 90 mm focal lengths are also available)
SMA 905
14 different gratings
5, 10, 25, 50, 100, or 200 µm slits. (Slits are optional. In the
absence of a slit, the fiber acts as the entrance slit.)
Sony ILX511 CCD
Selection of Long Pass Filters to eliminate 2
nd
order (optional)
Spectroscopic:
Integration Time
Dynamic Range
Signal-to-Noise
Readout Noise (single dark spectrum)
Resolution (FWHM)
Stray Light
Spectrometer Channels
3 – >30,000 msec
2 x 10
8
250:1 single acquisition
3.5 counts RMS, 20 counts peak-to-peak
0.03 – 10.0 nm varies by configuration
<0.05% at 600 nm; <0.10% at 435 nm
8 (master plus 7 slaves)
Environmental Conditions:
Temperature
Humidity
-30
° to +70° C Storage & -10° to +60° C Operation
0% - 90% noncondensing
000-00000-000-05-0704 3
