Apex Data Sheet
2 892-00000-000-05-201302
Features
 Back-thinned Hamamatsu uncooled detector S11510-1106
 High-throughput Virtual Slit
 Resolution (FWHM): <10 cm
-1
@ 800 nm
 Electrical Performance
- 16 bit A/D converter
 Communications: USB
 Software compatibility:
- SpectraSuite (1 complimentary license included with purchase)
- OmniDriver (sold separately)
- USB Programmer (available free from Ocean Optics)
- SeaBreeze (sold separately)
 Optical input: SMA 905
 Regulations:
- CE Mark
- RoHS
Specifications
Specifications Criteria
Physical Specifications:
Physical Dimensions (LxWxH)
Spectrometer Weight
254 mm (10 in.) x 167.6 mm (6.6 in.) x 81 mm (3.2 in.)
2.36 kg (5.2 lbs.)
Spectrometer:
Focal length (input)
Input Fiber Connector
Detector
Pixels
Pixel size
Spectral range
Well Depth
F/4 101.6 mm
SMA 905 to single-strand optical fiber (0.22 NA)
Hamamatsu S11510-1106 Back-thinned FFT-CCD
2048 x 64 (effective); 2068 x 70 (total)
14µm
2
780 – 1120 nm (>3800 cm
-1
)
300 Ke-
Spectroscopic:
Integration Time
Dynamic Range (Typical)
Signal-to-Noise
Nonlinearity (uncorrected)
7.2ms – 5s
15000:1
450:1
<1.0%
Environmental Conditions:
Temperature
Humidity –30° to +70° C Storage & –0
° to +50° C Operation
0% – 90% noncondensing
Interfaces:
USB USB 2.0
