background image

1: Setup and Operation

2

000-specc-110-02-201203

SpectroClip Models

SpectroClip includes the following models:

Model

Purpose

Included Equipment

Other Recommended
Equipment*

SpectroClip-R

Collects reflected light from
the sample

One integrating sphere

Spectrometer, one light
source, two fibers

SpectroClip-TR Collects both transmitted

and reflected light from the
sample

Two integrating spheres Two spectrometers (or

one 2-channel Jaz), one
light source, three fibers

Jaz-SpectroClip-TR Performs

transmission

and

reflectance characterization
of (thin) samples in the field

Two integrating
spheres; a Jaz
spectrometer (400 –
1000 nm) with two
spectrometer channels,
a tungsten-halogen light
source module, and a
battery module; 3 fibers,
and the Spectro-Clip-TR
probe

N/A

* Fibers are sold separately. The recommend fiber core is 600 µm or larger because of the attenuation of
the sphere.

Unpacking SpectroClip

The following sections provide instructions on unpacking and setting up your SpectroClip.

Before using the SpectroClip for the first time, check for transport damage. Be sure to adhere to all
warnings on the unit and in this manual.

Procedure

1. Unpack your SpectroClip device carefully.

2. Inspect the outside of the instrument and make sure that there is no damage. Do not use the

instrument if damage is present.

3. Detach the outer side of the fiber protection and inspect the SMA connectors. Do not use the

instrument if damage is present.
