USB-ISS-UV/VIS Installation and Operation Instructions
2 175-00000-000-01-201208
Parts Included
The USB-ISS-UV-VIS Integrated Sampling System ships with the following components:
• USB-ISS-UV/VIS miniature deuterium tungsten halogen light source
• 5-volt DC power supply
• SMA Collimator for spectrometer SMA coupling
Installing the Sampling System
Do not attempt to connect the USB-ISS-UV/VIS to the spectrometer without following the installation
instructions in this section. Furthermore, ensure that the spectrometer operating software (OOIBase32
or SpectraSuite) is installed on your PC and that the spectrometer is obtaining data before connecting
the USB-ISS-UV/VIS.
WARNINGS
• The light beam emitted from the USB-ISS-UV/VIS contains
ultraviolet radiation and can cause eye damage. Always use safety
goggles when working with this product.
• DO NOT OPEN THE USB-ISS-UV/VIS. The USB-ISS-UV/VIS has
an internal high voltage power source. Dangerous voltage levels are
present, and there are no user-serviceable parts.
• The USB-ISS-UV/VIS has an internal high voltage power source.
Thus, you should not adjust the unit while it is connected to a power
source.
• Contact Ocean Optics for bulb replacement.
• Do not use this instrument for any clinical or diagnostic
measurements.
• Dropping the unit can cause permanent damage. Handle with care.
Adjusting the Cuvette
►
Procedure
1. Locate the ball plunger screws (accessed on the front face of the unit and through the hole
opposite the power jack on the side of the unit).
2. Use a small flathead screwdriver to loosen the ball plunger screws until the end is visible in
the holder.
