1: Setup

2

000-10000-191-02-201309

Models Available

DH-3 Series light source models are available in regular (230 – 1100 nm) and extended (EXT models)
(230 – 2400 nm) wavelength ranges. The following models are available in the DH-3 Series:

Model

Calibrated Wavelength Range Minimum Uncertainty

Level

Shutter?

DH-3-BAL-CAL

230 – 1100 nm

10%

No

DH-3-BAL-CAL-EXT

230 – 2400 nm

10%

No

In addition the following plus versions are available which reduce the percentage of uncertainty to ~4%
and offer a shutter:

Model

Calibrated Wavelength Range Minimum Uncertainty

Level

Shutter?

DH-3 plus-BAL-CAL

230 – 1100 nm

4%

Yes

DH-3 plus-CAL-EXT

200 – 400 & 350 – 2400 nm

3.7%

Yes

The following sections provide instructions on unpacking and setting up your DH-3 Series Light Source.

Unpacking the DH-3 Series Light Source

Procedure

1. Unpack your lamp assembly and power supply carefully. Although the lamp is rigidly mounted,

dropping this instrument can cause permanent damage.

2. Inspect the outside of the instrument and make sure that there is no damage. Do not use the

instrument if damage is present.

3. Use this instrument in a clean laboratory environment (see

Operating Environment

).

Contents

Your DH-3 Series Light Source package should contain the following:

DH-3 light source unit

Power cord

Lamp Calibration Report for using the DH-3 light source with a CC-3-UV-S cosine-corrected
irradiance probe

1 CD that holds files for lamp calibration reports

1 Allen wrench for adjusting the cosine corrector
