Crown Audio I-Tech 4x3500HD - Manual (Page 47)

I-Tech HD DriveCore Series Power Amplifiers
Operation Manual page 47
Performance i-T4x3500Hd
Damping Factor (8 ohms): 20 Hz to 100 Hz > 5000
Crosstalk (below rated power, 20 Hz to 1 kHz) > 80 dB
Common Mode Rejection (CMR) (20 Hz to 1 kHz) > 55 dB, typically > 70 dB
DC Output Offset (Shorted input) < ± 3 mV
Input Impedance (nominal) 20 kilohms balanced, 10 kilohms unbalanced
Load Impedance (Note: Safe with all types of loads)
Stereo
Bridge Mono
2-4-8-16 ohms, 70V/100V
2-4-8 ohms, 70V//100V
Required AC Mains Universal AC input, 100-240VAC +-10%,
50/60 Hz. Max. AC mains voltage.
AC Line Connector USA, UK, European, Australia, India, Brazil, China
(USA ships with Hubbell L6-30)
Construction i-T4x3500Hd
Ventilation Flow-through ventilation from front to back
Cooling Dual-zone, microprocessor controlled,
continuously variable speed fans
Dimensions EIA Standard 19-inch rack mount width (EIA
RS-310B), 3.5-inch (8.9-cm) height, 16.95-inch
(43.1-cm) depth behind front mounting surface
Weight
Net
Shipping
29 pounds (13.1 kg)
37 pounds (16.8 kg)
9 Specifications
