P.I.P.-ISO
Page 9
filter set to flat. Less than 0.5% THD
for +18 dBm input above 100 Hz
with bass filter set to flat.
Input Impedance: Nominally 10 K
ohm.
Maximum Source Impedance for
Proper Isolation:
600 ohms.
Maximum Input Level: +20 dB at
1 kHz.
Nominal Gain: Unity.
Frequency Response: ±1 dB
from 20 Hz to 15 kHz when sub-
sonic/bass filters set flat. The sub-
sonic/bass (high-pass) filters have
selectable –3 dB roll-off points of
50, 100 or 300 Hz (see Figure 3.6)
and can be switched off if desired.
A permanent RFI filter with a –3 dB
roll-off at 33 kHz also affects the
response.
Dimensions: 6 3 /8 x 1 7 /8 x 3 7 /8 in
(16.2 x 4.8 x 9.8 cm).
Weight: 14 ounces (397 grams).
®
E106377
4 Specifications
Note: All specifications referenced
to a 0.775 V input signal.
Signal to Noise: Better than –90
dB (equivalent input noise) 20 Hz
to 20 kHz.
Common Mode Rejection: 85 dB
at 1 kHz; 78 dB at 10 kHz; 68 dB at
15 kHz.
Crosstalk: –85 dB at 1 kHz; –82
dB at 10 kHz; –80 dB at 15 kHz.
Harmonic Distortion: Less than
0.01% THD for 0 dBm input at 1
kHz with bass filter set to any posi-
tion. Less than 0.5% THD for +10
dBm input above 50 Hz with bass
Applies only to
North American
units.
