Install the spout on the baseplate.
Tighten the screws using a 3 mm Allen wrench.
(1) Wrap the threads on the nipple using Teflon tape.
() Install the nipple using an 1 mm Allen wrench
(not included). It should extend 1⅛" mm outside the
surface of the finished wall.
(1) Push the baseplate against the wall.
() Install the nuts.
(3) Tighten the spout screws using a 3mm Allen
wrench.
7
3 mm
!
3 mm
8
1.
.
3.
12 mm
9
1.
.
