English installation – Factory Direct Hardware Hansgrohe 11043 User Manual
Page 4
4
English
Installation
(1) Remove the caps.
() Cut the plaster shields so that they extend ¹⁄₁₆"
outside the surface of the finished wall.
(3) Seal the wall around the i-box
with waterproof sealant.
Failure to seal the wall can lead to
possible water damage.
Remove the hot cartridge.
Install the new hot cartridge included with the trim kit.
21
1.
.
3.
Silicone
3
2
