English, Installation with spout at the left – Factory Direct Hardware Hansgrohe 11435 Axor Urquiola User Manual
Page 8
8
English
Install the function block.
Tighten the screws using a 4 mm Allen wrench.
(1) Remove the plugs.
() Open the stops.
(3) Flush the supplies.
Turn the water off at the volume control.
Installation with spout at the left*
Measure the distance between the
front plaster shield and the front of the
spout port ("X").
*Installation with the spout on
the right -- see page 16.
3.
4
5
2.
1.
17 mm
6
