6
English
Place a dab of silicon at the grout joints.
Push the escutcheon assembly over the nipples.
Tighten the spout screw using a 3 mm Allen wrench.
Tighten the shower holder screw using a mm Allen
wrench.
(1) Place a hose washer in the short hose end. Con-
nect this end of the hose to the handshower holder.
() Place the screen washer in the long hose end.
Connect this end to the handshower.
Rest the handshower in the holder.
20
2.
1.
21
19
*Silicon
