10

English

Cut the spout nipple so that it is X + ¹⁄₁₆" long.

Measure the distance between the front of the plaster
shield and the front of the shower port ("X").

Cut the shower nipple so that it is X + 1¹³⁄₁₆" long.

7

!

8

9

!

X + 2¹⁄₁₆"

X + 1¹³⁄₁₆"
