Add 1 ¾” to this measurement.
Cut the connecting thread so that it is X + 1 ¾” long.
Wrap the threads on the connecting thread with Teflon
tape (1).
Use an 8 mm Allen wrench to install it in the rough ().
Do not overtighten the connecting thread!
(3) Push the handle escutcheon against the wall. Install
the nut, color ring, and handle fixing set. Tighten the
screw.
The connecting thread should extend 1 1/8” outside the
surface of the finished wall.
1
2
3
