Push the spout sealing ring firmly into the spout
tee.
Install the spout escutcheon.
Press the spout over the spout tee. Install and
tighten the screw with a 3 mm Allen wrench.
CAUTION: do not overtighten the screw or the o-
rings on the diverter will deform, which will cause
a leak.
Turn on the water and check all connections for
leaks.
