Page 4
4
Installation - 3-Hole Trim Kits
If you are using a 4-Hole set, please turn to page 6
Install the Handles
Remove the plaster shields from the hot and cold
valves and the spout tee.
Install the Spout
Remove the brass plug from the tee.
Install the handle escutcheons.
Install the white plastic snap connectors and the
screws.
Push the handle down firmly over the snap
connectors.
