Replacement Parts
1
diverter knob
96086XX0
2
aerator cpl.
94034XX0
3
spout cpl. 10444XX1
96163XX0
4
spout cpl. 10458XX1
96138XX0
5
selector assy
94037000
6
handle
10991XX0
7
escutcheon for shower holder
94052XXX
8
filter packing (25)
94246000
9
handshower
38885XX1
10 shower holder, assy
92380XX0
11 hose 2,00 m
94148000
12 check valve
94074000
4
XX = Colors
00 = chrome
81 = satinox
82 = brushed nickel
