PM3327A3527A_a
3327A/3527A VERTICAL RODS AND LATCHES
Item No.
Quantity
Part No.
Description
Finish
1
2
034902
325 Sex Bolt Package (Pkg of 2)
X
2
1
050401
33/3527A Bottom Latch Kit Less Cover
3
1
050400
33/3527A Top Latch Kit Less Cover
4
1
050512
3327A Top Rod Kit
X
4
1
050513
3527A Top Rod Kit
X
5
1
050514
3327A Bottom Rod Kit
X
5
1
050515
3527A Bottom Rod Kit
X
6
2
105952
33/3527A Rod Guide Pkg
X
7
1
900589
Latch Mounting Package (Pkg of 4)
8
2
900850
Latch Case Cover Screw (Pkg of 2)
X
9
2
900565
Rod Guide Mounting Package
10
4
090054
Rod Roll Pin (Pkg of 10)
11
6
090055
Housing Guide Pin (Pkg of 10)
12
2
090065
Bolt Return Spring (Pkg of 10)
13
1
090056
Top Latch Compression Spring (Pkg of 10)
13
1
090057
PL Top Latch Spring (Pkg of 10)
14
1
090058
Bottom Latch Case Spring (Pkg of 10)
15
2
090067
Rod Connector - Latch (Pkg of 2)
16
2
090068
Rod Connector - Center Case (Pkg of 2)
17
2
050496
Latch Case Cover Kit w/Screws
X
18
1
090076
Aux. Bolt Spring (Pkg of 10)
19
2
050546
Latch Case Mtg. Bracket
20
1
090075
Rod Extension Connector (Pkg of 4)
X in “Finish” column designates finished items; finish must be specified when ordering.
