Page 3 of 14 PM3327A3527A_a
STANDARD STRIKES
OPTIONAL STRIKES FOR PANIC EXIT HARDWARE
499F (Top) Strike - Supplied
with LBR Fire Latch/Strike Kit
260U (Top) Strike
For Flush Transom
Applications Only
304L
(Bottom) Strike
385A
(Bottom) Strike
1
Metal Door Screw Package PKGSRV.1023 (Pkg of 10)
Wood Door Screw 964291 (Qty of 1)
Screw Pkg
900252 Adjusting Shim
945521
1
264 (Top) Strike - Single
Door Panic Exit Hardware
299 (Top) Strike - Standard
Single or Double Door
Panic Exit Hardware
248L-4
(Bottom) Strike
266
(Top) Strike
Adjusting Shim 945521
Strike Hook 969300
1
Screw Pkg
900263
Adjusting Shim 970321
Strike Plate
970323
1
Adjusting Shim
945521
1
299 (Top) Strike - Standard
Single or Double Door
Panic Exit Hardware
Screw Pkg
900266
386DT*** 386NL**
360T-BE* 360L
388NL-OP****
OUTSIDE TRIM FUNCTIONS
* “BE” (Blank Escutcheon) no cylinder used - lever always active
** “NL” (Night Latch) rigid lever - key retracts latch bolt
*** ”DT” (Dummy Trim) rigid lever for pull operation
**** “NL-OP” (Optional Pull) needs to be added
360L-BE*
360L-DT***
360T
33A/35A SERIES FINISHES
US3
US4
US10
US15
US26
US26D
US28
313AN
315AN
605
606
612
619
625
626
628
710
711
Polished Brass
Dull Brass
Dull Bronze
Satin Nickel
Polished Chrome
Dull Chrome
Anodized Alum. (Clear)
Anodized Alum. (313)
Dark Bronze
Anodized Alum. (Black)
U.S. Std
Reference
BHMA
Reference Description
