PM3327A3527A_a

3327A/3527A LX (LATCH BOLT MONITOR) &
RX (REQUEST TO EXIT) OPTIONS

1

2

LX Switch

RX Switch

Wire Colors

Violet, Gray, White

(for Low Current

Violet, Gray, Black)

Wire Colors

Red, Yellow, Blue

(for Low Current

Green, Yellow, Blue)

7

8

7
