Factory Direct Hardware Hansgrohe 32314 Talis S User Manual
Page 4
4
Installation - 3-Hole Trim Kits
If you are using a 4-Hole set, please turn to page 6
Install the Handles
Remove the plaster shields from the hot and cold valves
and the spout tee.
Assemble the Spout
Remove the brass plug from the tee.
Install the handle escutcheons.
Install the white plastic snap connectors and the screws.
Push the handle down firmly over the snap connectors.
