adjustment with the shower hose to be used.
2. DECIDE ON MOUNTING METHOD
On any smooth surface such as tile, fiberglass,

marble, etc., the special mounting tape attached

to the rail is usually satisfactory by itself. For

best adhesion of the mounting tape, do not

mount rail directly over a vertical ceramic tile

line. On any rough surface such as uneven tile,

etc., the screws provided should be used in

addition to the tape.
3. MOUNT GLIDE RAIL
A. Adhesive Bonded Mounting Procedure:
Clean Surface - If mounting tape only is used,

the wall surface must be thoroughly cleaned. To

achieve maximum adhesion, it is necessary that

the surface be free of any residue. If the wall

surface is not absolutely dry and clean, the self-

adhesive backing will not stick properly. To clean

most surfaces, nail polish remover, rubbing

alcohol, or lighter fluid can be used, (Be sure to

follow the precautions noted on the container.)

A mild abrasive cleaner should be used if

silicone or wax has been applied to the wall.
Mount Rail - Peel protective covering from

tape, being careful not to touch or otherwise

contaminate the adhesive. Position rail and

press firmly into place by rubbing on the rail with

the heel of your hand. NOTE: For best results

allow the adhesive to dry for a minimum of 4

hours before using shower.
B. Screw Mounting Procedure:
Remove Glide Rail end caps by inserting the

blade of a screwdriver between the end of

the rail and end cap (on rear side of rail) and

prying off.
Mark screw hole positions on the wall. Drill 1/4”

holes as near the center of the slotted holes as

possible for the screw anchors provided (use a

carbide tipped drill for ceramic tile or concrete).
Peel adhesive protective covering from Glide

Rail and install as in 3A above, being sure the

slotted holes are aligned with the screw anchors

before pressing into place. Install screws and

tighten until the tape is slightly compressed.
Replace chrome end caps by tapping on the

caps lightly with a hammer until they snap into

place. Protect the caps with a cloth or other soft

substance while striking.
4. MOUNT HAND SHOWER.
Mount the hand shower on glide rail and attach

to water supply. Tighten hose nuts sufficiently to

slightly compress the urethane hose ends which
act as gasket seals.

Lifetime Faucet and Finish

Limited Warranty

All parts and finishes of the Delta

faucet

are warranted to the original consumer

purchaser to be free from defects in material

& workmanship for as long as the original

consumer purchaser owns their home. Delta

Faucet Company recommends using a

professional plumber for all installation & repair.
Delta will replace, FREE OF CHARGE,

during the warranty period, any part or finish

that proves defective in material and/or

workmanship under normal installation, use &

service. Replacement parts may be obtained

by calling 1-800-345-DELTA (in the U.S. and

Canada) or by writing to:

In the United States:
Delta Faucet Company

Product Service

55 E. 111th Street

Indianapolis, IN 46280

In Canada:
Masco Canada Limited, Plumbing Group

350 South Edgeware Road,

St. Thomas, Ontario, Canada N5P 4L1

This warranty is extensive in that it covers

replacement of all defective parts and even

finish, but these are the only two things that

are covered. LABOR CHARGES AND/OR

DAMAGE INCURRED IN INSTALLATION,

REPAIR, OR REPLACEMENT AS WELL AS

ANY OTHER KIND OF LOSS OR DAMAGES

ARE EXCLUDED. Proof of purchase (original

sales receipt) from the original consumer

purchaser must be made available to

Delta for all warranty claims. THIS IS THE

EXCLUSIVE WARRANTY BY DELTA FAUCET

COMPANY, WHICH DOES NOT MAKE

ANY OTHER WARRANTY OF ANY KIND,

INCLUDING THE IMPLIED WARRANTY OF

MERCHANTABILITY.
This warranty excludes all industrial,

commercial & business usage, whose

purchasers are hereby extended a five year

limited warranty from the date of purchase,

with all other terms of this warranty applying

except the duration of the warranty. This

warranty is applicable to Delta

faucets

manufactured after January 1, 1995.
Some states/provinces do not allow the

exclusion or limitation of incidental or

consequential damages, so the above

limitation or exclusion may not apply to you.

Any damage to this faucet as a result of

misuse, abuse, or neglect, or any use of other

than genuine Delta

replacement parts WILL

VOID THE WARRANTY.
This warranty gives you specific legal rights,

and you may also have other rights which vary

from state/province to state/province. It applies

only for Delta

faucets installed in the United

States of America, Canada, and Mexico.
