Page 9 of 16 PM8827_A
END CASE KIT AND END CASE PARTS
Item No. Part No. Description Quantity Finish
1 050435 88 R/M/V End Case Kit X
88 R/M/V End Case 1
10-24 x 1-1/2” OPHMS 4
10-24 x 2” OPHMS 4
10-12 x 10-24 x 2” OPHCS 4
2 050436 8827-F/8875-F/8847-F End Case Kit X
88SV/CV/M-F End Case 1
10-24 x 1-1/2” OPHMS 4
10-24 x 2” OPHMS 4
10-12 x 10-24 x 2” OPHCS 4
3 090003 88 End Case Spring Pkg. 2
3 090080 88 End Case Spring Pkg. 10
4 050451 88 End Case Spring Stop Kit 1
5 050476 88/88-F End Case Spring Tube 1
6 050477 88/88-F Spring Tube Bracket w/Screws Kit
88/88-F Spring Tube Bracket 1
88/88-F Spring Tube Bracket Screws 2
7 900503 88 Center or End Case Mtg. Pkg. (CS and MS screws) X
10-24 x 1-1/2” OPHMS 4
10-24 x 2” OPHMS 4
10-12 x 10-24 x 2” OPHCS 4
7 900504 88 Center or End Case Mtg. Pkg. (CS screws) X
10-12 x 10-24 x 2” OPHCS 4
7 900505 88 Center or End Case Mtg. Pkg. (MS screws 1-3/4” door) X
10-24 x 1-1/2” OPHMS 4
7 900506 88 Center or End Case Mtg. Pkg. (MS screws 2-1/4” door) X
10-24 x 2” OPHMS 4
X in “Finish” column designates finished item; specify finish when ordering.
