Item No. Part No. Description Quantity Finish
1 090007 Axle Security Pin Pkg. 10
1 033022 Axle Security Pin Pkg. 50
2 090004 Dog Screw Pkg. 2
2 090083 Dog Screw Pkg. 10
3 090005 227 Dog Key 5/32” Pkg. 2
3 090085 227 Dog Key 5/32” Pkg. 10
4 090006 88 Lever Arm Axles
88 Axle Separator 2
88 Axle - Male 2
88 Axle - Female 2
4 090082 88 Lever Arm Axles
88 Axle Separator 10
88 Axle - Male 10
88 Axle - Female 10
5 090008 Wedgetite Screw Pkg. 2
5 090081 Wedgetite Screw Pkg. 30
6 090020 Crossbar Tube Attaching Wedge Pkg. 2
7 090021 Crossbar Tube Attaching Ring Pkg. 2
8 103865 88 Lever Arm Axle Pkg.
Cyliner Anchor Plate 1
88 Axle Separator 1
88 Axle - Male 2
88 Axle - Female 2
X in “Finish” column designates finished item; specify finish when ordering.
LEVER ARM PARTS PACKAGES
