Page 16 of 16 PM8827_A
VERTICAL RODS
Item No. Part No. Description Quantity Finish
1 050453 8827 Top Rod Kit 1 X
2 050454 8827-F Top Rod Kit 1 X
3 050455 8827 Bottom Rod Kit 1 X
4 050456 8827-F Bottom Rod Kit 1 X
5 090010 8827/27-F Bottom Rod Roll Pin Pkg. 10
6 051701 8827 12” Extension Rod Kit 1 X
7 051703 8827 24” Extension Rod Kit 1 X
8 050093 8827 Extension Rod Coupling 1
9 050482 8827 Rod Guide Kit 1 X
10 900534 8827 Rod Guide Mounting Pkg. X
10-12 x 10-24 x 1 PTHCS 2
X in “Finish” column designates finished item; specify finish when ordering.
1
2
5 8
9
10
6
7
Includes
extension rod
coupling
3
4
Includes bottom
rod connector
and roll pin
