NPPA-TT-S Instruction Manual
Standard solder lugs enable a reliable and long-lasting wiring.
Termination with solder lugs Solder bridges
Solder tags
6. Cable retention to the unit
The built in cable retention bar is at the back of the casing. Simply attach the cables with cable
ties to the bar as shown in the photo.
For large and heavy bundles there is an additional strain relief bar NPPA-S available. It is
attached to the casing with four screws.
Cable Retention Bar
