NPPA-TT-S Instruction Manual
10. Ordering Information
Patch Panels
Part Number
Description Configuration*
Wiring
Grounding
NPPA-TT-S
2 x 48 jacks half normalled bottom
288 solder terminals individual
NPPA-TT-S-FN
2 x 48 jacks full normalled
288 solder terminals individual
NPPA-TT-S-HNT
2 x 48 jacks half normalled top row
288 solder terminals individual
NPPA-TT-S-I
2 x 48 jacks isolated
288 solder terminals individual
NPPA-TT-S-P
2 x 48 jacks parallel
288 solder terminals individual
* fully loaded jack pairs only
Pre-configured Jack-Pairs
Part Number
Description
Configuration*
NJ3TTA-4-HNB blocks of 2 channels half normalled bottom row
cover ident color: clear
NJ3TTA-4-HNT blocks of 2 channels half normalled top row
cover ident color: yellow
NJ3TTA-4-FN
blocks of 2 channels full normalled
cover ident color: green
NJ3TTA-4-P
blocks of 2 channels parallel
cover ident color: red
NJ3TTA-4-I
blocks of 2 channels isolated
cover ident color: orange
Accessories
NPPA-S
Strain Relief bar
NKTT*
Patch cords with NP3TT-1 plugs. Available in black, blue, green, red and
yellow. Length: 30, 40, 60, 90, 120 cm
NPPA-NB
Normalling bars for changing the normalling of all 48 channels
Standard supply
The compact Neutrik ”Easy Patch” NPPA-TT-S consists of:
• Black coated steel casing with aluminium fittings
• 2 x 48 highly integrated Neutrik
NJ3TTA jacks with gold plated double contacts and specially
designed normalling mechanism (standard: half normalled bottom row)
• Integrated internal pre-wiring with selectable flexible grounding system
• Solder lugs termination
• 2 Built–in cable retention bars
• Spare normalling configuration bars
4 Normal 1: “short”, bridges 5 contacts
8 Normal 2: “medium”, bridges 6 contacts
4 Normal 3: “long”, bridges 7 contacts
• 1 Disassembling plier
• 1 Instruction Manual
