6. Experiments

6.1 Measuring the intensity of “solar radiation”

Place the water-filled cuvette, and the air-filled
absorption chamber behind it, in the incoming
beam.

Measure the intensity of the transmitted radia-
tion with the thermopile.

Replace the air-filled absorption chamber with
the one that contains butane, and again meas-
ure the intensity of the transmitted radiation
with the thermopile.

Result of the measurements: the thermopile shows
about the same intensity in both cases. Thus, bu-
tane only has a small effect on the absorption of
solar radiation.

6.2 Measuring the intensity of the long-wave

infrared radiation

Place the black metal disc, and the air-filled
absorption chamber behind it, in the incoming
beam.

Wait about two minutes for the black metal disc
to become warm.

Measure the intensity of the transmitted radia-
tion with the thermopile.

Replace the air-filled absorption chamber with
the one that contains butane, and again meas-
ure the intensity of the transmitted radiation
with the thermopile.

Result of the measurements: when butane is pre-
sent in the absorption chamber, the thermopile
shows a considerably lower intensity being transmit-
ted than in the case of absorption by air alone.
