27
Experiment 10 - Measuring voltage Student instructions
Assembly, charging and discharging of a steel accumulator
Chemicals Hazard
symbols
R phrases S phrases Equipment
Meter
Potassium hydroxide 20%
approx.
(
≈
4 molar)
22-35 26-36/37/39-45 Electrodes:
1 Ni, 1 Fe
Distilled water --- --- 2 Experiment cables
2 Pipettes
Warning: Be careful when handling potassium hydroxide! Wear protective glasses!
Experiment procedure:
1. The suitably concentrated potassium hydroxide (20%) required for the experiment should be given to the students.
2. Assemble the battery block as described.
3. Fill two opposing half cell chambers with 20% potassium hydroxide.
4. Insert an iron electrode into one chamber and a nickel electrode into the other.
5. To charge up the cell, connect the 3V adapter so that the nickel electrode is connected to the + pole and the iron
electrode is connected to the - pole.
6. After connecting the 3V adapter to the mains power supply and plugging the latter into the 230V mains, allow the
accumulator to charge up for about 10 minutes.
7. The 3V adapter is then replaced by the meter and the voltage produced by the accumulator can then be measured.
Observation and evaluation:
Sketch of experiment set-up:
Observation for the experiment:
