H.264 Super Digital Video Recorder User Manual
20
Zoom: Click / button to adjust the zoom multiple of the camera.
Focus: Click / button to adjust the focus of the camera.
Iris: Click / button to adjust the iris of the camera.
Direction control: Control the PTZ rotation. 8 directions control is supportive. (4 directions in Front
panel is supportive).
PTZ Trace: Full-screen show channel image. Left press mouse and control PTZ to rotate orientation.
Left press mouse and then rotate the mouse to adjust the zoom multiple of the camera.
Set: Enter the function operation menu.
Page Switch: Switch between different windows.
Special Functions:
1、Preset
Set a location for the preset, calls the preset points, PTZ automatically turns to the setting position.
1）Preset option
Set a location for the preset, procedure is as follows:
Step1: in Picture 3.8, click the Direction button will turn into preset position, click the Settings button
to enter Picture 3.9.
Step 2: click the Preset button, and then write the preset points in the input blank.
Step 3: click Set button, return the Picture 3.8 Complete setup, that is the preset points and preset
position corresponds.
Remove Preset：Input preset points, click Remove button, remove the preset.
Picture 3.9 Preset Settings
2）Preset Point Calls
In Picture 3.8, click Page Shift button, enter PTZ control interface as shown in Picture 3.10. In
Preset button
Preset point input blank
