7.10.2 Hook Inspection


The wear on the top hook and the load hook SHALL be checked routinely. Measure the throat
opening (dimension

a

2 - FIGURE 21). If the throat opening exceeds the maximum opening allowed,

replace the hook. Damaged safety latches shall be replaced immediately.

Figure 21. Hook Dimensions


LOAD

CAPACITY

(LBS)

TEST

LOAD

FALLS

MINIMUM

FAILURE

LOAD

CLASS

1389

2778

1

8752

025T

2205

4409

1

11023

025T

2756

5512

2

17361

05T

4409

8818

2

22046

05T

HOOK DIMENSIONS – INCHES

ØM

Øa1

a2

a3

b1

b2

e1

h1

h2

t1

t2

0.630

1.417

1.024

1.614

0.866

0.748

3.780

1.102

0.945

1.496

0.512

0.630

1.417

1.024

1.614

0.866

0.748

3.780

1.102

0.945

1.496

0.512

0.787

1.693

1.339

1.929

1.142

0.945

4.134

1.457

1.221

1.496

0.551

0.787

1.693

1.339

1.929

1.142

0.945

4.134

1.457

1.221

1.496

0.551

Initial Dimension – a2

Max. Allowed Dimension

Mark: ISO 2766

1.024 inches

1.178 inches maximum

DIN Model Number: 15401

1.339 inches

1.540 inches maximum

DIN 15400 Class: T

DIN 15401 Material: 35 CD 4
