RESISTANCE
Range Resolution Accuracy
200Ω 0.1Ω
±(0.8% of rdg + 5 digits)
2k
Ω
1
Ω
±(0.8% of rdg + 5 digits)
20k
Ω 10Ω
±(0.8% of rdg + 5 digits)
200k
Ω 100Ω
±(0.8% of rdg + 5 digits)
2M
Ω 1kΩ
±(1.0% of rdg + 5 digits)
Maximum Open Circuit Voltage: 2.8V
Overload Protection: 250V DC or rms. AC for all ranges.
TRANSISTOR hFE TEST (0-1000)
Range Test Range Test Current Test Voltage
NPN & PNP 0-1000 Ib=10mA Vce=2.8V
BATTERY TESTING
Range Accuracy
1.5V ±(2.5% of rdg + 2 digits)
OPERATING INSTRUCTIONS DC VOLTAGE
MEASUREMENT
1. Connect the red test lead to the "V
ΩmA
" jack and the
black test lead to the "COM" jack.
2. Rotate the function selector to the desired DCV position. If the
voltage to be measured is not known, set the selector to the
highest range position, and then reduce the range until proper
resolution is obtained.
3. Connect test leads across the source or load being measured.
4. Read voltage value on the LCD display along with the polarity
of the red test lead connection.
