SPECIFICATIONS
Accuracy is specified for a period of one year after calibration
and at 18°C to 28°C(64°F to 82°F) with relative humidity to 80%.
GENERAL
Maximum voltage between : CAT III 600V
Terminals and earth ground
Fuse protection : F 10A/250V
Power : 1.5V, AAx2
Display : LCD, 1999 counts, updates 2-3/sec.
Measuring method : Dual-slope integration A/D converter
Over range indication : Only figure "1" on the display
Polarity indication : "-" displayed for negative polarity
Operating environment : 0 to 40ºC
Storage temperature : -10ºC to 50ºC
Low battery indication : "
" appears on the display
Size : 147mm x 78mm x 41mm
Weight : Approx. 183g
DC VOLTAGE
Range
Resolution
Accuracy
200mV
100uV
±(0.5% of rdg + 2 digits)
2V
1mV
±(0.5% of rdg + 2 digits)
20V
10mV
±(0.5% of rdg + 2 digits)
200V
100mV
±(0.5% of rdg + 2 digits)
500V
1V
±(0.8% of rdg + 5 digits)
Overload Protection: 250V rms. For 200mV range and 500V DC
or rms. AC for other ranges.
