3
0.025-0.25-25uF
(C2)
 3% FSD.
Use the optional
Accessory Kit
(MT-2007-C) Capacitan
ce (uF)
2000uF(C1) Approx.
Value
Use the R x 1K range
BATT
Check 0 ~ 1.5V: GOOD
- ? – BAD
0 ~ 9V: GOOD
- ? – BAD  5% of
ARC of
Scale
Length Load Current:
270mA for 1.5V
25mA for 9V
Overload protected by
Fuse & Oxide
Varactor .<250V
AC/DC(5s).
Transistor
Check hFE: 0-1000 via
special hFE
socket Approx.
Value At Ω X 10 Range
LED,
Diode
Check via special hFE
socket Approx.
Value At Ω X 10 Range
Decibel -22 dB ~ + 62 dB
(0dB=1mW at
600Ω) Approx.
Value At ACV ranges
Continuity
Check Beeper sounding
under 200 Ohm Overload protected by
Fuse & Oxide
Varactor .<250V
AC/DC(5s).
POWER
Source Internal Battery:
R6P, AA, 1.5V
2pcs, 6F22,
NEDA1604, 9V
1pc
CALIBRATION
Ohms Zero Adjustor located at the right side of the panel,
adjusting the meter pointer to the Zero mark on the right side
of Ohm scale of the meter dial when the test leads are touched
together.
Mechanical Adjustor Screw: located right below the center of
the meter dial to set pointer to Zero mark at the left side of the
