Prokit's Industries MT-2018 - Manual (Page 4)

3
Midscale at 200KΩ
0.025-0.25-25uF
(C2)
 3% FSD.
Use the Optional
Accessory Kit
MT-2007-C Capacit
ance
(uF)
2000uF(C1) Approximate
Value
Use the R x 1K
range
BATT
Check 0 ~ 1.5V: GOOD
- ? – BAD
0 ~ 9V: GOOD - ?
– BAD  5% of ARC
of Scale
Length Load Current:
270mA for 1.5V,
25mA for 9V.
Overload protected
by Fuse & Oxide
Varactor .<250V
AC/DC(5s).
Transist
or
Check hFE: 0-1000 via
special hFE socket Approximate
Value At Ω X 10 Range
LED,
Diode
Check via special hFE
socket Approximate
Value At Ω X 10 Range
Decibel -22 dB ~ + 62 dB
(0dB=1mW at
600Ω) Approximate
Value At ACV ranges
POWE
R
Source Internal Battery:
R6P, AA, 1.5V
2pcs, 6F22,
NEDA1604, 9V 1pc
