Prokit's Industries MT-5210 - Manual (Page 3)

3
4. CHARACTERISTIC
1 GENERAL
1-1
Displaying: LCD displaying.
1-2 Max. displaying: 1999 3 1/2 digit auto polarity indication.
1-3 Measuring method: dual slope A/D conversion.
1-4 Sampling rate: approx. 3 times/second.
1-5 Over range indication: the MSD displays“1”.
1-6 Low battery indication:“ ” appears.
1-7 Operation environment: 0 40 ℃ R.H.<80% .
1-8 Power 9V×1 NEDA1604/6F22 or equivalent model .
1-9 Size:189Ч97Ч35mm
1-10 Weight: approx. 362g without battery .
1-11. Accessory: operation manual, gift box, test leads
2 TECHNICAL CHARACTERISTIC
Accuracy:±(a%× rdg d) at (23±5)℃
R.H.<75%
2-1. Inductance (L)
RANGE ACCURACY RESOLUTION
MEASURE
FREQUENCY
2mH 1uH
20mH 10 uH
200mH
±(2.0%+5d)
100uH
2H ±(5.0%+5d) 1mH
20H ±(5.0%+15d) 10mH
About 200Hz
1H=10³mH=10
6
uH
