2
1. SUMMARIZE
The meter is a stable multimeter with 3 2/1 LCD displays , 9V drive by
battery. It's widely used on measuring Inductance, resistance,
capacitance, diode, transistor rest and continuity buzzer. It’s an ideal
tool for lab, factory and family.
2. SAFETY NOTE
The meter meets the standards of IEC1010. Read the operation
manual carefully before operation.
1 Do not input DC Voltage or AC Voltage.
2 The voltage below 36V is safety. To avoid electric shock, check
whether the test leads are connected correctly, whether the
insulation is good when measuring over 36DCV or 25ACV, .
3 Remove the test leads when changing function and range.
4 To select correct function and range, beware of error operation.
5 SAFETY SYMBOLS
“ ”THE OPERATOR MUST REFER TO THE MANUAL “ ” LOW
BATTERY
3. Technical data
Function Model
Inductance
2mH-20H
Capacitance 2nF-1000uF
Resistance 200Ω-20MΩ
Diode test √
Transistor Test √
Continuity buzzer √
Data Hold √
Alarm √
