Maintenance
60 7
Engine compartment sub fuse panel (Sub-relay box)
Engine compartment main fuse panel (Engine junction fuses)
Description Fuse rating Protected component
OPCU 80A OPCU Relay
C/FAN 60A C/FAN HI Relay
Relay No. Relay Name Type
E41 RR HTD Relay PLUG MICRO
E42 PDM 1 (ACC) Relay PLUG MICRO
E43 Water Pump Relay PLUG MICRO
E44 C/FAN (LO) Relay PLUG MICRO
E47 Deicer Relay PLUG MICRO
E49 PDM 2 (IG1) Relay PLUG MICRO
E50 PDM 3 (IG2) Relay PLUG MICRO
E51 Wiper Relay PLUG MICRO
E52 Rain SNSR Relay PLUG MICRO
E53 B/Horn Relay PLUG MICRO
E54 Blower Relay PLUG MICRO
