Your vehicle at a glance
4 2
ENGINE COMPARTMENT
1. Sub relay box ....................................7-55
2. Engine coolant reservoir ...................7-24
3. Windshield washer fluid reservoir .....7-29
4. Radiator cap .....................................7-26
5. Engine oil dipstick .............................7-22
6. Engine oil filler cap ...........................7-22
7. Brake fluid reservoir..........................7-28
8. Air cleaner.........................................7-30
9. Fuse box ...........................................7-52
10. Inverter coolant reservoir ................7-24
* : if equipped
* The actual engine room in the vehicle may differ from the illustration.
OYFH071001
