Maintenance
58 7
Engine compartment main fuse panel
Description Fuse rating Protected component
MULTI
FUSE
IP B+ 2
60A
I/P Junction Box (P/SEAT DRV 30A, P/SEAT PASS 20A, AMP 30A, PDM 2 7.5A, IPS 5,
IPS 6, ARISU 2)
AHB 1 60A Hydraulic Power Unit
IGN 2 40A E/R Fuse & Relay Box (PDM 3 (IG 2) Relay)
ESC 1 40A ESC Module
RR HTD 40A E/R Fuse & Relay Box (RR HTD Relay)
BLOWER 40A E/R Fuse & Relay Box (Blower Relay)
IP B+ 1 60A
I/P Junction Box (PDM 1 25A, MODULE 3 7.5A, S/HEATER FRT 20A, S/HEATER RR 15A,
TRUNK 10A, P/WDW LH 25A, P/WDW RH 25A), Power Connector (AUDIO 15A))
MDPS 80A EPS Control Module
FUSE
WIPER 10A PCM
RR HTD IND 10A A/C Control Module
OPCU 1 20A Electric Oil Pump Unit
INVERTER 10A MCU, Low Voltage DC-DC Converter, Active Air Flap
TCU 1 20A PCM
STOP LP 15A Hybrid Fuse & Relay Box (HAC Relay), Smart Key Control Module, Stop Lamp Relay
DEICER 20A E/R Fuse & Relay Box (Deicer Relay)
WATER PUMP 10A E/R Fuse & Relay Box (Water Pump Relay)
BMS C/FAN 20A BMS Blower Motor Relay
IP B+ 3 50A
I/P Junction Box (Power Connector (ROOM LP 10A), SUNROOF 20A, DR LOCK 20A, BMS 10A,
IPS 1, IPS 3, ARISU 1)
ESC 2 30A Multipurpose Check Connector, ESC Module
HCU 20A Hybrid Control Unit
AHB 2 30A Hydraulic Power Unit
